12,000GS Rotary Magnetic Filter
Product Introduction
12,000GS Rotary Magnetic Filter is composed of stainless steel housing and grate magnet.The inside grate magnet is rotated by motor driving to remove ferromagnetic contamination from super fine, high viscosity and poor fluidity materials that is prone to clogging, caking or bridging.
Optional:
Housing material : SS304/SS316
Surface treatment: brushing ,sandblasting, polishing
Coating options: salt bath nitriding, Tungsten carbide,PTFE, PFA, ETFE
Magnet options: NdfeB / Smco /Ferrite
Contact Us to Get Started
Description
Reviews
Rotary Magnetic Filter is composed of stainless housing and grate magnet.The inside grate magnet is rotate by motor driving to remove ferromagnetic contaminations from super fine, high viscosity and poor fluidity materials that is prone to clogging, caking or bridging. It is are widely used in building materials, chemical, coal, food, refractory, pharmacy, etc.
| Name | 12,000GS Rotary Magnetic Filter |
| magnet Material | Ndfeb magnet /ferrite magnet/smco magnet |
| Surface treatment | sandblasting/polishing/brushing |
| Coating | teflon,tungsten carbide |
| Food grade welding | available |
| Working Temparature | 0-350℃ |
| Housing material | SS304/SS316 |
| Max magnetic strengh | 14,000GS |
| Monthly Output | 10,000pcs |
| MOQ | 1pc |
| Port | Ningbo |
| Packing | wood case |
| Lead time | 40days |
