Pipeline Magnetic Liquid Trap
Description
Reviews
Magnetic pipeline trap with quick interface connector is goor for tightness and easy to be installed which is applied for
removing ferrous contamination from liquid or semi-liquid materials.
1.Housing:SS304 or SS316L
2.Surface treatment: sand blasting /polishing/brushing
3.Magnetic intensity :1500-13000GS
4.Max working temparature: from 80 to 350
5.Magnet materials : Samarium-Cobalt (rare-earth),Ceramic , Neodymium-Iron-Boron(rare-earth)
6.Food grade welding: availble
7.Custom made :available.your logo/brand/pattern can be printed on
8.MOQ:1PC
9.Lead time:30days
10.Packing:standard brown carton/wood case
11.Payment term: T/T
12.Loading Port:Ning Bo/Shang Hai
Magnetic Liquid Filter,inline magnet,pipeline magnetic filter,Liquid Magnetic trap
| MODEL NO | Dimension(mm) | ||||||
|---|---|---|---|---|---|---|---|
| A | B | C | D | E | F | L | |
| SW-E10 | 2S | 47.8 | 1S | 23 | 60 | 226 | 350 |
| SW-E10-1 | 2S | 47.8 | 1S | 23 | 55 | 226 | 340 |
| SW-E15 | 2S | 47.8 | 1.5S | 35.7 | 60 | 226 | 350 |
| SW-E20 | 2.5S | 59.5 | 2S | 47.8 | 110 | 226 | 450 |
