Radial Ferrite Magnets
Description
Reviews
Radial Ferrite Ring Magnets are producted by two production method: anisotropic dry pressing or anisotropic wet pressing .they are Mag Spring s special magnetic product. Ideal for using in the industries of permanent magnetic motor, magnetic rotating, Magnetic sensor, magnetic timer,etc.
Radially Magnetized Ferrite Ring Magnet with different size
D21.6 24poles magnetized ring magnets about 1500Gs by dry pressing or 1800Gs by wet pressing
D36.2 4poles magnetized ring magnets with 1450-1550Gs by dry pressing or 1900Gs by wet pressing D23.4 8poles magnetized ring magnets with 1600Gs-1700Gs by dry pressing or 1900Gs by wet pressingD20 12poles magnetized ring magnets with 1500Gs by dry pressing or 1800Gs by wet pressing
16 poles magnetized ring magnets with 1400-1500Gs by dry pressing or about 1800Gs by Wet pressing
Radially Ferrite Ring Magnet with 24 Poles
Radially Ferrite Ring Magnet with 24 poles
Radially Ferrite Ring Magnet with 4 poles
Radially Ferrite Ring Magnet with 8 poles
Radially Ferrite Ring Magnet with 12 poles
Radially Ferrite Ring Magnet with 16 poles
