10,000GS Easy Cleaning Grate Magnet
Description
Reviews
As a leading NdFeB magnet manufacturer in China, MAG SPRING provides high-performance Easy Cleaning Magnetic Grate / Easy Cleaning Magnetic Grill for iron impurity removal. Made of stainless steel tubes and powerful rare earth magnets, it achieves quick and automatic cleaning. When magnetic bars are pulled out from the stainless steel sleeve, fine ferrous contamination falls off automatically, making maintenance extremely efficient.
Easy Cleaning Magnetic Grate is widely used in food, plastic, chemical, pharmaceutical and other industries that require high-standard purification and iron removal.
Product Overview
Easy Cleaning Magnetic Grate is a high-efficiency magnetic filtration device composed of stainless steel housing and strong magnetic rods. It is widely used in dry powder, granular material pipelines and hoppers to adsorb iron impurities such as iron nails, screws, rust, and iron filings. The unique easy-cleaning design allows users to quickly remove magnetic rods and clean adsorbed impurities without tools, greatly improving production efficiency.
It is an ideal iron removal equipment for food industry, plastic industry, chemical industry and pharmaceutical industry.
Key Specifications
- Housing Material: SS304 or SS316L Stainless Steel
- Surface Treatment: Sand Blasting / Mirror Polishing
- Magnetic Intensity: 1500GS – 10,000GS
- Max Working Temperature: 80℃ – 350℃ (customizable)
- Magnet Material: Neodymium-Iron-Boron, Samarium-Cobalt, Ferrite Ceramic
- Food Grade Welding: Available
- Custom Service: Logo, Brand, Pattern can be printed
- MOQ: 1 PC
- Lead Time: 30 days
- Packing: Standard brown carton / wooden case
- Payment Term: T/T
- Loading Port: Ningbo / Shanghai
Features & Advantages
- Quick & tool-free cleaning design, save labor cost
- High-intensity magnetic field, effectively adsorb fine iron impurities
- Stainless steel 304/316L housing, food-grade & corrosion-resistant
- High-temperature resistant magnets available up to 350℃
- Food-grade welding, meets international hygiene standards
- Customizable size, magnetic strength and installation method
- Stable performance, long service life, low maintenance cost
- Compliant with EU RoHS, ISO9001, ISO14001 standards
Applications
Easy Cleaning Magnetic Grate is widely used in many industries for iron impurity removal:
- Food Industry: grain, sugar, salt, flour, milk powder, tea, snacks
- Plastic Industry: plastic particles, recycled materials, masterbatch
- Chemical Industry: powder, pigment, chemical raw materials
- Pharmaceutical Industry: traditional Chinese medicine powder, capsules, raw materials
- Other industries: feed, ceramics, new energy materials, etc.
Working Principle
When materials pass through the magnetic grate, ferromagnetic impurities are instantly adsorbed on the surface of the magnetic rod under strong magnetic force. After a period of use, the user can pull out the magnetic core assembly, and the impurities will automatically fall off from the stainless steel sleeve, realizing fast cleaning without disassembly tools.
Learn more about magnet principles: https://en.wikipedia.org/wiki/Magnet
Quality & Certifications
- ISO9001 Quality Management System Certified
- ISO14001 Environmental Management System Certified
- EU RoHS Environmental Directive Compliance
- Food-grade material certification
- 100% magnetic performance test before shipment
Production & Delivery
- MOQ: 1 piece, sample orders are accepted
- Custom size & magnetic strength available
- Standard export packaging, safe transportation
- Fast delivery from Ningbo/Shanghai port
FAQs
Q: What materials are used for the housing?
A: We use SS304 or SS316L food-grade stainless steel.
Q: What is the magnetic strength range?
A: 1500GS to 10,000GS, can be customized.
Q: Can it work under high temperature?
A: Yes, max working temperature can reach 350℃ with SmCo magnets.
Q: Is food-grade welding available?
A: Yes, fully meet food and pharmaceutical industry standards.
Q: Do you accept custom orders?
A: Yes, size, magnetic force, logo and installation can be customized.
