Magnetic Separator Price List: How Much Does It Cost in 2026?
_1787651443_WNo_1600d900.webp)
If you are evaluating magnetic separation equipment for a mining, recycling, or mineral processing project, one of the first questions you will ask is: how much does a magnetic separator cost? The short answer is that magnetic separator prices in 2026 range from as low as US$1,000 for basic pulley-type units to well over US$400,000 for large-scale WHIMS (Wet High Intensity Magnetic Separation) systems and fully customized separation plants. This wide range exists because magnetic separators are not a single product category — they span a broad spectrum of designs, magnetic field intensities, processing capacities, and configurations, each engineered for specific material types and separation objectives.
This guide provides a comprehensive, data-informed magnetic separator price list for 2026. Rather than offering a single number that cannot possibly capture the market reality, we break down pricing by separator type, application, capacity, and configuration, and explain the key cost drivers that determine the final quote. We also cover total cost of ownership, new versus used equipment considerations, and what to include when requesting a quote from suppliers. All price ranges referenced in this article are based on publicly available 2026 market data from manufacturers and B2B marketplaces including Alibaba and Made-in-China.
Magnetic Separator Price in 2026: Quick Answer
Before diving into the details, here is a concise overview of typical magnetic separator price ranges in 2026. These are indicative ranges based on publicly available market quotes and should be used as budget-planning references rather than fixed prices. Actual quotes depend on specifications, order volume, customization requirements, and shipping destination.
| Magnetic Separator Type | Typical 2026 Price Range |
|---|---|
| Magnetic Pulley | US$1,000–10,000+ |
| Magnetic Drum Separator | US$1,500–15,000+ |
| Overband Magnetic Separator | US$2,000–15,000+ |
| Wet Drum Magnetic Separator | US$2,500–30,000+ |
| Dry Magnetic Separator | US$2,000–15,000+ |
| High Intensity Magnetic Separator | US$5,000–50,000+ |
| Rare Earth Roll Separator | US$8,000–30,000+ |
| WHIMS | US$20,000–400,000+ |
| Customized Magnetic Separation System | US$50,000–400,000+ |
Magnetic Separator Price List by Type
Understanding pricing at the type level is essential because each magnetic separator design serves a fundamentally different purpose. A magnetic pulley designed for simple tramp iron removal on a conveyor costs a fraction of a WHIMS unit built to separate weakly magnetic minerals from slurry at high throughput. The sections below provide detailed pricing breakdowns for each major separator category, including the key specifications that influence cost within each type.
Magnetic Drum Separator Price
| Variable | Entry Level | Mid Range | Heavy Duty |
|---|---|---|---|
| Price | US$1,500–3,000 | US$3,000–8,000 | US$10,000–15,000+ |
| Drum Diameter | 300–600 mm | 600–1,000 mm | 1,000–1,200+ mm |
| Working Width | Under 600 mm | 600–1,500 mm | 1,500–3,000+ mm |
| Magnet Type | Ferrite / Ceramic | Rare Earth | High-Intensity Rare Earth |
| Typical Applications | Grain, aggregates | Recycling, bulk materials | Mining, continuous industrial processing |
Wet Drum Magnetic Separator Price
| Variable | Entry Level | Mid Range | Heavy Duty |
|---|---|---|---|
| Price | US$2,500–6,000 | US$6,000–15,000 | US$15,000–30,000+ |
| Drum Diameter | 600–750 mm | 900–1,200 mm | 1,200+ mm |
| Capacity | 5–20 TPH | 20–50 TPH | 50–150+ TPH |
| Tank Configuration | Standard | CTS / CTB | Multi-Stage CTS / CTB |
| Typical Applications | Small mineral processing | Magnetite concentration | Iron ore beneficiation |
Dry Magnetic Separator Price
| Variable | Entry Level | Mid Range | High Performance |
|---|---|---|---|
| Price | US$2,000–5,000 | US$5,000–10,000 | US$8,000–15,000+ |
| Drum / Roll Diameter | 300–600 mm | 600–1,000 mm | 100–1,000+ mm |
| Capacity | 1–10 TPH | 5–30 TPH | 1–50+ TPH |
| Magnet Type | Ferrite / Ceramic | Rare Earth | High-Intensity Rare Earth |
| Typical Applications | Coal, grain, aggregates | Dry mineral processing | Silica, feldspar, kaolin purification |
High Intensity Magnetic Separator Price
| Variable | Compact | Medium | Advanced |
|---|---|---|---|
| Price | US$5,000–12,000 | US$12,000–30,000 | US$30,000–50,000+ |
| Working Width | 500–1,000 mm | 1,000–2,000 mm | 1,500–2,000+ mm |
| Magnetic Intensity | 8,000–10,000 Gauss+ | 10,000–15,000 Gauss+ | High-Intensity Magnetic Circuit |
| Separation Stages | Single Roll | Multiple Rolls | Multi-Stage |
| Automation | Manual | Partial Automation | PLC / Automated Control |
Rare Earth Roll Separator Price
| Variable | Single Roll | Double / Triple Roll | Multi-Roll |
|---|---|---|---|
| Price | US$8,000–15,000 | US$15,000–25,000 | US$25,000–30,000+ |
| Roll Diameter | 100–300 mm | 100–300 mm | 300+ mm |
| Working Width | 500–1,000 mm | 500–1,500 mm | 1,500+ mm |
| Capacity | 1–5 TPH | 2–10 TPH | 5–20+ TPH |
| Typical Applications | Industrial mineral purification | Silica, feldspar, kaolin | High-purity mineral processing |
WHIMS Price
| Variable | Laboratory / Pilot | Medium Production | Large Industrial |
|---|---|---|---|
| Price | US$20,000–40,000 | US$40,000–100,000 | US$100,000–400,000+ |
| Canister Diameter | 100–200 mm | 500–1,000 mm | 1,000+ mm / Multiple Canisters |
| Capacity | <1 TPH | 5–20 TPH | 20–100+ TPH |
| Magnetic System | Electromagnetic | Electromagnetic | High-Power Electromagnetic |
| Automation | Basic | PLC Control | Automated Backwash / PLC |
Overband Magnetic Separator Price
| Variable | Manual Clean | Self-Cleaning | Heavy Duty |
|---|---|---|---|
| Price | US$2,000–5,000 | US$5,000–10,000 | US$10,000–15,000+ |
| Conveyor Width | Under 1,000 mm | 1,000–1,500 mm | 1,500–2,500+ mm |
| Magnet Type | Ferrite / Ceramic | Ferrite / Rare Earth | High-Intensity Rare Earth |
| Cleaning Method | Manual | Automatic Belt | Automatic Continuous Cleaning |
| Typical Applications | Small recycling lines | Recycling, aggregates | Mining, waste management, heavy-duty processing |
2026 Magnetic Separator Price Comparison
The table below provides a side-by-side comparison of the major magnetic separator types, organized by relative price level, capacity range, magnetic intensity, and typical application. This comparison is designed to help procurement teams quickly identify which separator categories are relevant to their specific requirements and budget range.
| Type | Price Level | Capacity | Intensity | Typical Application |
|---|---|---|---|---|
| Magnetic Drum | $–$$ | Medium–High | Low–Medium | Iron removal, concentration |
| Wet Drum | $$–$$$ | High | Low–Medium | Iron ore processing, heavy minerals |
| Dry Drum | $$–$$$ | Medium–High | Medium | Dry mineral processing, tramp iron |
| Rare Earth Roll | $$$ | Medium | High | Mineral purification, silica sand cleaning |
| WHIMS | $$$–$$$$ | High | Very High | Fine mineral separation, hematite processing |
| Overband | $–$$ | High | Medium | Conveyor tramp iron removal |
This comparison underscores a critical procurement principle: selecting a magnetic separator based solely on price or capacity is insufficient. The optimal choice depends on the specific material being processed, the required separation efficiency, the feed characteristics (particle size, moisture content, magnetic susceptibility of both target and gangue minerals), and the processing environment. A low-cost drum separator may be perfectly adequate for removing tramp iron from crushed aggregate, but entirely unsuitable for purifying silica sand to glass-grade specifications where a rare earth roll or WHIMS unit is required.
Magnetic Separator Price by Capacity
Processing capacity is one of the most frequently used parameters for initial equipment sizing and budget estimation. However, capacity alone is not enough to determine the price, as the same 50 TPH capacity might require a fundamentally different and differently priced separator depending on whether the application is iron ore wet drum separation or silica sand high-intensity dry roll separation. The table below provides general indicative price ranges by capacity tier, based on standard configurations across common applications.
| Capacity Range | Indicative Equipment Price |
|---|---|
| 1–5 TPH | US$1,000–10,000 |
| 5–20 TPH | US$3,000–20,000 |
| 20–50 TPH | US$5,000–40,000 |
| 50–100 TPH | US$10,000–80,000 |
| 100+ TPH | US$30,000–400,000+ |
As an illustration of why capacity alone is insufficient, consider two very different 50 TPH scenarios. The first is a 50 TPH iron ore wet drum magnetic separator — this would typically be a large-diameter (1,000–1,200 mm) wet drum in a heavy-duty tank configuration, priced in the US$15,000–30,000 range. The second is a 50 TPH silica sand processing line with high-intensity rare earth roll separators — this would likely require multiple RER units in parallel or series, with vibratory feeders, splitter systems, and dust enclosures, potentially pushing the magnetic separation equipment cost to US$30,000–60,000 or more despite the same nominal throughput. The material characteristics, required separation efficiency, and processing method (wet versus dry) all exert as much influence on the final price as the tonnage rate alone.
What Factors Affect Magnetic Separator Price?
Magnetic separator prices are mainly affected by the following factors, which buyers should consider when comparing supplier quotations.
Magnetic Field Strength
Higher magnetic intensity and more complex magnetic circuit designs generally increase equipment cost, while field gradient and effective separation depth should also be considered.
Equipment Size
Larger drum diameters, wider working surfaces, bigger tanks, and larger electromagnetic components require more materials and stronger structures, resulting in higher prices.
Processing Capacity
Higher throughput requires larger equipment, stronger drive systems, heavier-duty components, and sometimes automated feeding and control systems, increasing the overall cost.
Feed Particle Size
Fine and ultra-fine materials usually require high-gradient magnetic systems or specialized feed designs, making them more expensive than separators for coarse materials.
Magnet Material
Ferrite magnets are generally more economical, while NdFeB rare earth magnets and electromagnetic systems cost more because they provide higher intensity or greater control.
Wet vs Dry Configuration
Wet magnetic separators usually cost more because they require slurry tanks, water-handling components, corrosion protection, and additional sealing and bearing protection.
Automation
Features such as VFDs, PLC control, automatic cleaning, sensors, and remote monitoring can increase the initial price but improve operational efficiency.
Customization
Non-standard dimensions, special materials, customized magnetic circuits, and production-line integration typically increase the price compared with standard models.
New vs Used Magnetic Separator Price
Buying used or refurbished magnetic separation equipment can significantly reduce the initial capital outlay, but it also introduces risks that must be carefully evaluated. The table below compares the three primary purchasing options across key decision criteria.
| Option | Initial Cost | Risk Level | Warranty | Best For |
|---|---|---|---|---|
| New | Higher | Low | Usually available (1–3 years) | Long-term production, critical processes |
| Used (as-is) | Lower | Medium–High | Limited or none | Budget-constrained projects, non-critical applications |
| Refurbished | Medium | Medium | Depends on supplier | Cost-conscious buyers wanting some assurance |
Used magnetic separators are typically available at 30–70% of the new equipment price, depending on age, condition, and the specific model. However, buyers of used equipment must perform thorough due diligence before purchase. The most critical inspection points include: magnet strength verification (permanent magnets can demagnetize over time, especially if exposed to high temperatures or physical shock); drum shell condition (wear, corrosion, or damage to the shell surface can affect separation performance); bearing and seal condition (worn bearings can cause drum misalignment and uneven separation); motor and gearbox condition (including insulation resistance testing and vibration analysis); drive belt or chain condition (where applicable); and a review of the previous operating history, including hours of operation, type of material processed, and maintenance records.
For permanent magnet separators, verifying that the magnets still produce their rated field strength is the single most important inspection. Magnet degradation is not always visible externally, and a separator with weakened magnets will deliver poor separation performance regardless of its mechanical condition. Buyers should request a gauss meter reading of the drum or roll surface field before finalizing a used equipment purchase. Refurbished units from reputable dealers typically include new magnets or magnet recharging, new bearings, new drive components, and a limited warranty, providing a middle ground between the low cost of as-is used equipment and the full price and warranty coverage of new equipment.
FAQs
1. Does a higher Gauss rating mean a more expensive and better magnetic separator?
Higher magnetic intensity can increase equipment cost, but Gauss alone does not determine separation performance because magnetic field gradient, working distance, particle size, and material susceptibility are also important. Instead of asking only for the maximum Gauss value, request the magnetic field profile and performance test results using material similar to your actual feed.
2. How does processing capacity affect magnetic separator price?
Higher processing capacity generally requires larger magnetic surfaces, stronger drive systems, heavier structures, and better feed and discharge systems, which increase the equipment cost. When requesting a quotation, provide your normal and peak throughput rather than choosing a machine based only on the supplier's maximum advertised TPH, because actual capacity depends on material characteristics and feeding conditions.
3. What hidden costs should I consider when buying a magnetic separator?
Your budget should include more than the equipment price, including international shipping, installation, commissioning, electrical or water connections, conveyor modifications, spare parts, operator training, maintenance, and energy consumption. Ask suppliers to clearly separate equipment cost from these additional costs so you can calculate the actual landed cost before placing an order.
4. How can I avoid buying a magnetic separator that is too large or too small?
Size the separator according to your actual material characteristics and required throughput rather than simply buying the largest available model. An undersized separator can create bottlenecks and reduce separation efficiency, while excessive capacity can unnecessarily increase capital and operating costs; suppliers should therefore confirm the recommended model based on your actual feed conditions.
5. Should I ask the magnetic separator manufacturer to test my material before purchasing?
Yes, especially when processing fine particles, weakly magnetic materials, high-moisture feed, or high-purity products. Send a representative material sample and ask the manufacturer to provide test results showing separation efficiency, recovery, product grade, and recommended operating conditions, because laboratory or standard-material results may not accurately represent your production feed.
Conclusion
Looking for the right magnetic separator at the right price? MAG SPRING can help you select a magnetic separation solution based on your material, processing capacity, separation requirements, and budget. With more than 20 years of manufacturing experience, a 20,000 m² factory, and a wide range of magnetic separation equipment, including magnetic drums, overband separators, dry magnetic separators, wet magnetic separators, and electromagnetic separators, MAG SPRING provides both standard and customized solutions.
Instead of choosing a separator based on price alone, contact MAG SPRING to discuss your application and receive a suitable equipment recommendation and quotation. Contact MAG SPRING for a Magnetic Separator Quote and let their technical team help you find a cost-effective solution for your project.
